Input Voltages | Control | ||
100V~240V AC，50/60Hz | DMX512, 5-pin interfaces(Optional 3-pin) | ||
22channels in short mode, 26channels in standard mode, | |||
Input Power | 30channels in extended mode,Self-test mode | ||
800W @ 220V | |||
Current at Maximum 8A | Other Functions | ||
Power factor: PF〉0.9 | Adjustable Pan & Tilt speeds | ||
Lamp’s and fixture’s hours displayed | |||
Light Source | Modular Structure for easy maintenance | ||
PHILIPS MSD Platinum 25 R (7800,1500hours) | DMX512 wireless receiever | ||
PHILIPS MSD Platinum 500L Flex (550W) (Optional) | DMX512 Wireless Transmitter（Optional） | ||
ArtNet（Optional） | |||
Independent Cto System | Housing | ||
Linear CTO system | Cast Aluminum and high temperature and UV resistant ABS, IP66 | ||
Prism/Frost | Net Weight | ||
3 pcs of prisms which can be overlapped | 39.8 Kg | ||
(8 facet circular prism+ 4facet linear prism) | |||
(16 facet circular prism+ frsot) And other optional prisms | Work Temperature | ||
Maximum ambient temperature: 45°C | |||
Focus | For a waterproof fixture: if the ambient temperature is minus 20 Celsius, | ||
DMX linear Focus | strike the lamp to pre-heat for 10minutes and reset it again. | ||
Dimmer/Strobe | Accessories | ||
0-100% Linearly adjustable/ Double shutter blades, 0.3~25 F.P.S | G clamps 2 Pcs | ||
XLR connector 1 Set Male and female | |||
Head Movement | Safety cord 1 Pc | ||
Pan 540o, Tilt 270o with auto position correction | User manual 0 Pc | ||
Ω clamps 2 Pcs Optional | |||
Beam Angle | |||
| Beam angle 2° | |||
| Color Wheel | |||
| CMY color mixing system with macros | |||
1 Color wheel: 12colors+ Open | |||
| rainbow effect with bi-directional and variable speeds | |||
| Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 18 gobos +Open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel:7 Interchangeable Gobos+Open | |||
Bi-directionally rotatable, and shakable at variable speeds Gobo Replaceable | |||
