Input Voltages |
Control |
||
|
100-240V AC, 50/60Hz |
International standard DMX512 signal and RDM function |
||
|
42channels in short mode, 47channels in standard mode,62channel in extended mode |
|||
|
Input power: |
Art Net protocol and sCAN protocol(optional), DMX512 wireless control |
||
|
1550W@220V，1700W@100V |
|
||
|
Control Interface |
|||
|
Light Source |
DMX512 ports（5-pin） |
||
|
1200W white LED( 6900K), 20000 hrs, CRI: Ra≥95( Optional high out version: Ra≥70) |
Ethernet port RJ45 |
||
|
|
|||
|
CTO |
Other Functions |
||
|
Linear CTO system(0-100%, 1800K-6500K) |
Pan and Tilt speeds adjustable |
||
|
Pan and Tilt swappable and invertible |
|||
| Dimmer |
High precision magnet sensor for positioning |
||
|
Linear electronic dimmer 0-100% with 16 bit control |
3.2-inch touch color screen, Chinese and English menus |
||
|
3 dimmer speeds |
Screen automatic lock –up while standby | ||
|
4 dimmer gamma curves |
Error diagnostic system with sensors |
||
|
Dimmer frequency(1.2K-25K) |
Smart fan cooling system | ||
| Display of fixture hours and software versions | |||
|
Framing |
Modular construction for easy maintenance | ||
|
4 framing blades to make graphics with different sizes and shapes Each blade to make |
Isolated input signals |
||
| full curtain effect,Continual and bi-directional rotation for the whole module |
Firmware update via DMX cable or USB port |
||
|
|
|
||
|
Effect |
Weight | ||
|
1 animation effect wheel, bi-directional rotation with varied speeds |
Net weight: 45kg |
||
|
|
|
||
|
Iris |
Physical |
||
|
Linear iris 5-100% with macros |
Housing: composite plastic, IP20 | ||
| Ambient working temperature: maximum 45°C | |||
|
Prism |
|
||
|
1pc of 4-facet circular prism+1 pc of linear prism |
|
||
| bi-directional rotation with varied speeds with indexing function |
|
||
|
|
Accessories | ||
|
Frost |
G clamp, 2 pcs |
||
|
2 frost filters: 1 heavy frost filter + 1 light frost filter (0-100% linear ) |
5 pins XLR connector, 1 set |
||
|
|
Safety cord, 2 pcs |
||
|
Beam Angle |
Power cord, 1 pc |
||
| Linear zoom 6°～ 54°with 16 bit precision |
Optional: Ω clamp, 2 pcs |
||
|
|
|||
|
Focus |
Packaging | ||
|
Linear focus with auto-focus function |
Standard: carton 555x655x820(mm) | ||
| Optional: flight case 725x625x855(mm) | |||
|
Strobe |
|||
|
Electronic strobe, 0.3~25 F.P.S |
|||
|
Head Movement |
|||
| Pan 540º, Tilt 270º with auto position correction and 16 bit control | |||
|
|
|||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| Color Wheel | |||
|
2 Color wheels: each with 6 dichroic colors filters plus open |
|||
|
Full color/half color/linear color |
|||
|
Bi-directional rainbow effect with variable speeds |
|||
| Fixed Gobo | |||
|
1 fixed gobo wheel:7 exchangeable gobos+ open |
|||
|
Shake effect with varied speeds and bi-directional rotation with varied speeds |
|||
| Rotating Gobo | |||
| 1 rotating gobo wheel: 6 exchangeable+ open | |||
|
Bi-directional rotation, indexing, shake with varied speeds |
|||
| bi-directional scrolling with varied speeds | |||
| Framing | |||
|
4 framing blades to make graphics with different sizes and shapes Each blade to make full curtain effect |
|||
|
Continual and bi-directional rotation for the whole module |
|||
