Input Voltages | Control | ||
100-240V AC, 50/60Hz | International DMX512, 5 pins(optional 3 pins) interface | ||
Short mode 22 channels, standard mode 26 channels, extended mode 30 channels | |||
Power Consumption | Self-test mode | ||
800W@220V | |||
Other Functions | |||
Light Source | Adjustable pan & tilt speed | ||
PHILIPS MSD Platinum 25R 550W, (7,800±300K, 1,500 hrs) | LCD display screen | ||
Optional: OSRAM SIRIUS HRI 550W XL, (7500±300K, 1,500 hrs) | Fixture and lamp hours display | ||
Modular structure for easy maintenance | |||
Strobe | DMX512 wireless receiver | ||
Double shutter blades, 0.3~25 F.P.S | DMX512 wireless transmitter(optional) | ||
Dimmer | Physical | ||
0-100% linear adjustment | Housing: high temperature engineering plastic, IP20 | ||
Ambient temperature: maximum 42°C | |||
CTO | |||
Independent 0-100% linear CTO | Weight | ||
Net weight: 25Kg | |||
Prism | |||
Three prisms(standard: 8-facet+16-facet+4-facet prism) | Packaging | ||
| bi-directional rotation with variable speeds, optional: 3-facet, gradient prisms | Standard: carton 770x730x654(mm) | ||
Optional: flight case 602x549x760(mm) | |||
Frost | |||
One frost filter | Accessories | ||
G clamp, 2 pcs | |||
Focus | 5 pins XLR connector, 1 set | ||
DMX linear focus | Safety cord, 1 pc | ||
Optional: Ω clamp, 2 pcs | |||
Head Movement | |||
Pan 540°, tilt 270° with auto position correction | |||
Light Angle | |||
2° | |||
| CMY | |||
CMY linear mixing system with macros CMY linear color mixing with macros | |||
| Color Wheel | |||
1 Color wheel: 12 dichroic color filters plus open | |||
Rainbow effect with bi-directional and variable speeds | |||
| Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 18 gobos plus open | |||
Bi-directionally rotatable, and shakable effect at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel: 7 interchangeable gobos plus open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
