Input Voltages | Head Movement | ||
100-240V AC, 50/60Hz | Pan 540°, tilt 270° with auto position correction | ||
Power Consumption | Control | ||
680W@220V | International DMX512, 5 pins(optional 3 pins) interface | ||
Short mode 23 channels, standard mode 28 channels, extended mode 33 channels | |||
Light Source | Self-test mode | ||
OSRAM SIRIUS HRI 470W S(7,800K±300K, 1,500 hrs) | |||
Other Functions | |||
Strobe | Adjustable pan & tilt speed | ||
Double shutter blades, 0.3~25 F.P.S | LCD display screen | ||
Fixture and lamp hours display | |||
Dimmer | Modular structure for easy maintenance | ||
0-100% linear adjustment | DMX512 wireless receiver | ||
DMX512 wireless transmitter(optional) | |||
Prism | |||
Two prisms(standard: 8-facet and 16-facet prisms) | Physical | ||
Optional: 3-facet/16-facet liner prism or gradient prism | Housing: high temperature engineering plastic, IP20 | ||
Bi-directional rotating at variable speeds | Ambient temperature: maximum 45°C | ||
Frost | Weight | ||
One frost filter | Net weight: 22Kg | ||
Diffuser | Packaging | ||
One independent diffuser(optional even beam mode) | Standard: carton 640x510x530(mm) | ||
Optional: flight case 860x550x750(mm) | |||
Focus | |||
DMX linear focus | Accessories | ||
G clamp, 2 pcs | |||
Zoom | 5 pins XLR connector, 1 set | ||
DMX linear zoom | Safety cord, 1 pc | ||
Optional: Ω clamp, 2 pcs | |||
Light Angle | |||
Beam mode: 2.3°~10° | |||
Spot mode: 5°~40° | |||
| Wash mode: 5°~50° | |||
| CMY | |||
CMY linear color mixing with macros | |||
| Color Wheel | |||
1 Color wheel: 13 dichroic color filters(with CTO) plus open | |||
Rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 10 gobos plus open | |||
Bi-directionally rotatable, and shakable effect at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel: 9 interchangeable gobos plus open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
