| Input voltage |
Advanced macros |
||
|
208V~240V AC，50/60Hz |
Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K |
||
|
Standard color macros: 89 color options based on standard color chart |
|||
|
Input power |
|||
|
1800W@220V |
Fixture types |
||
|
Including moving head light, fixed-focus profile light, zoom profile light |
|||
|
Light source |
Moving head light with beam angle range: 4-50° |
||
|
OSRAM lok-it 1400/PS |
Fixed focus profile light with beam angle options including 4°,10°,19°,26°,36°,50° |
||
|
Zoom profile light with beam angle ranges including 4-15°,15-35°,35-50° |
|||
|
Cto |
|||
|
0-100% Linear CTO system |
Control |
||
|
International standard DMX512 signal and RDM function |
|||
|
Prism |
Art Net protocol(optional) , sACN protocol(optional), DMX512 wireless control | ||
|
1pc 3-facet circular prism and 1pc 4 facet linear prism, indexing |
41channels in basic mode, 45channels in standard mode , 60channels in extended mode |
||
| bi-directional rotation with variable speeds |
Self-test mode |
||
|
|
|||
|
Frost |
Control interface |
||
|
2pc frost filters(1 light frost filter and 1 heavy frost filter), 0-100%linear adjustment |
DMX512 ports（5-pin） |
||
|
Ethernet port RJ45 |
|||
|
Effect wheel |
|
||
|
1 dynamic effect wheel, rotatable in both directions |
Other functions |
||
|
Adjustable Pan & Tilt speeds |
|||
|
Focus |
Lamp’s and fixture’s hours displayed | ||
|
DMX linear Focus with auto focus function |
Color touch screen, Chinese and English menus, brightness and contrast adjustable |
||
|
Energy saving ballast |
|||
|
Dimmer |
Sensor diagnostic system for errors |
||
|
0-100% Linearly adjustable |
Input signal isolated, modular construction and DMX channel power level monitoring |
||
|
Two dimmer curve options: linear and inverse square law |
Non-tangible mangentic sensor for positioning, signal feedback and absolute position saving |
||
|
The latter has wider dimmer range and more smooth dimming in dark places |
Auto-positioning after power off or DMX signal loss |
||
|
Firmware upgrade via DMX link |
|||
|
Iris |
|
||
|
5-100%linear adjustment with macro |
Physical |
||
|
High temperature resistant engineering plastic with IP20 |
|||
|
Strobe |
40°C at maximum | ||
|
Double blade strobe, 0.3-25 F.P.S |
|
||
|
|
|||
|
Head movement |
Weight |
||
|
Pan 540º, Tilt 270º with auto position correction |
44.5KG | ||
| Beam angle | |||
|
Linear zoom 4°～ 50° with 16 bit adjustment |
|||
| CMY | |||
|
CMY linear mixing system with macros |
|||
| Color Wheel | |||
|
1 Color wheel: 7 dichroic color filters plus open |
|||
|
Half color effect, rainbow effect with bi-directional and variable speeds |
|||
| Stepping/linear color changing | |||
| Rotating Gobo | |||
|
1 Rotating gobo wheels, 6 Interchangeable Gobos +Open |
|||
|
Bi-directionally rotatable, scrolling and shakable at variable speeds, indexing |
|||
|
1 fixed gobo wheel ,7 exchangeable gobo+ open |
|||
|
Bi-directionally rotatable, scrolling and shakable at variable speeds, indexing |
|||
|
Gobo size: 32mm |
|||
|
Gobo image size: 23mm |
|||
| Framing | |||
|
4 framing blades |
|||
|
Continual framing module rotation, to make graphics of different sizes and shapes |
|||
|
4 framing blade to make full curtain effect |
|||
