Input Voltages | Other Functions | ||
100-240V AC, 50/60Hz | Adjustable pan & tilt speed | ||
LCD display and its brightness adjustable | |||
Power Consumption | Lamp temperature & project’s use time display | ||
650W@220V | Menu invert function | ||
DMX512 wireless receiver | |||
Light Source | DMX512 wireless transmitter(optional) | ||
CREE 61x10W LEDs(RGBW, 4 in 1), 50,000 hrs | |||
Physical | |||
Strobe | Housing: high temperature, ABS+die-casting aluminum, IP20 | ||
Electronic strobe, 0-25 F.P.S, pulse strobe | Ambient working temperature: -20°C~40°C | ||
Dimmer | Weight | ||
0-100% linear adjustment | Net weight: 20.3kg | ||
Head Movement | Packaging | ||
Pan 540o, tilt 270o with auto position correction | Standard: 560x525x435(mm) | ||
Swap and invert functions of pan and tilt | Optional: 1127x520x745(mm) 2 in 1 | ||
Light Angle | Accessories | ||
Beam angle(1/2 peak): 13°~52° | Power cord, 1 pc | ||
Filed angle(1/10 peak): 30°~70° | G clamp, 2 pcs | ||
5 pins XLR connector, 1 set | |||
Control | Safety cord, 1 pc | ||
International DMX512, 3 pins and 5 pins interface | Optional: Ω clamp, 2 pcs | ||
RDM control protocol | |||
Standard mode 17 channels and extended mode 30 channels | |||
| Master/salve mode, stand-alone mode, static scene mode, self test mode | |||
| Color System | |||
R/G/B/W and color mixing, with macros | |||
Rainbow and animation effects | |||
| Color Temperature | |||
Linear color temperature correction from 2,700K to 10,000K | |||
