Input Voltages |
Light Angle |
||
|
100-240V AC, 50/60Hz |
22°~55° |
||
|
|
|||
|
Power Consumption |
Other Functions |
||
|
200W@220V |
LED lamp board temperature and fixture time available in the menus |
||
|
DMX channel mode and settings displayed |
|||
|
Light Source |
LCD and inverted display |
||
|
1 COB 150W LED (RGBW 4 in 1), 50,000 hrs |
Display backlight automatically shut off after delay |
||
|
Parameters like operation mode and etc. transmitted under synchronization |
|||
|
Strobe |
DMX512 wireless receiver |
||
|
Electronic strobe, 0.5-33 F.P.S |
DMX512 wireless transmitter(optional) |
||
|
|
|||
|
Dimmer |
Weight |
||
|
Linear Dimming from 0-100%
|
Net weight: 7.5kg |
||
|
|
|||
|
Control |
Packaging | ||
|
DMX512, 3 pin interfaces |
Standard: carton 700x690x480(mm) |
||
|
7channels in standard mode and 12channels in extended mode |
Optional: flight case 440x465x585(mm), 6 in 1 |
||
|
Master/Slave Mode |
|
||
|
3 Operation Modes(DMX Mode, Preset Memory, user Memory) |
Accessories |
||
|
Test mode |
C clamp, 1 pc |
||
|
Safety cord, 1 pc |
|||
|
Physical |
Signal adapter cable, 2 pcs | ||
|
Housing: high intensity die-casting alloy, IP67 |
Power adapter cable, 1 pc | ||
|
Ambient working temperature: -20°C~40°C |
Optional: barndoor, 1 set | ||
| Color System | |||
| R/G/B/W and color mixing , with macro | |||
