Input Voltages | Control | ||
100-240V AC, 50/60Hz | International DMX512, 5 pins interface | ||
Short mode 35 channels, standard mode 38 channels and extended mode 54 channels | |||
Power Consumption | Art Net protocol | ||
880W@220V, 930W@100V | Master-slave mode, stand-alone mode, self-test mode | ||
Light Source | Other Functions | ||
600W white LED(8,000K), 20,000 hrs | Adjustable pan & tilt speed | ||
Ra≥70, R9≥90, Ra≥95 Lamp(optional） | Color touch panel display in English, and its brightness and contrast adjustable | ||
Fixture and lamp usage time display | |||
Strobe | Built-in analyzer for easy fault finding, error messages | ||
Electronic strobe, 0.3-25 F.P.S | Setup options by chargeable battery inside without power connection | ||
Software version display | |||
Dimmer | Modular structure easy for maintenance | ||
0-100% linear adjustment | Network interface | ||
DMX512 wireless receiver | |||
CTO | DMX512 wireless transmitter(optional) | ||
0-100% linear CTO system | |||
Weight | |||
Prism | Net weight: 45kg | ||
One 4-facet prism, bi-directionally rotatable at variable speed, indexable | |||
Packaging | |||
Frost | Standard: carton 845x645x790(mm) | ||
One linear frost filter | Optional: flight case 710x550x860(mm) | ||
Effect | Physical | ||
1 Replaceable animation wheel, bi-directionally rotatable atvariable speed | Housing: composite plastic, IP20 | ||
Ambient working temperature: maximum 45°C | |||
Iris | |||
5-100% linear adjustment with macro | Accessories | ||
G clamp, 2 pcs | |||
Focus | 5 pins XLR connector, 1 set | ||
Motorized linear focus | Safety cord, 2 pcs | ||
Power cord, 1 pc | |||
Head Movement | Optional: Ω clamp, 2 pcs | ||
Pan 540o, tilt 270o with auto position correction | |||
Swap and invert functions of pan and tilt | |||
Light Angle | |||
6°~56° | |||
| CMY | |||
CMY linear color mixing with macros | |||
| Color Wheel | |||
1 Color wheel: 6 dichroic colors filters plus open | |||
Half color effect, variable speed rainbow effect | |||
| Stepping/linear color changing is optional | |||
Linear color temperature adjustment | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 7 replaceable gobos plus open | |||
| Rotating Gobo | |||
1 Rotating gobo wheel: 6 replaceable gobos plus open, glass or metal gobos can be fixed | |||
Bi-directionally rotatable and wheel scrolling at variable speed, indexable | |||
Shakable at variable speeds | |||
| Framing | |||
| 4 Sets of framing blades | |||
Endless rotation, graphics at different sizes and shapes, full curtain effect | |||
