Input Voltages |
Other Functions | |||
|
100V-240V AC，50/60Hz |
Pan and Tilt speeds adjustable | |||
|
Pan and Tilt swappable and invertible |
||||
|
Input Power |
Touch color screen, Chinese and English menus, brightness and contrast adjustable |
|||
|
1500W@220V |
Error diagnostic system with sensors |
|||
|
Power factor: PF>0.95 |
Display of fixture hours and software versions |
|||
|
|
Modular construction for easy maintenance |
|||
|
Light Source |
Isolated input signals |
|||
|
Lamp 1200W ,LED white(8000K,20000hrs) |
ArtNet interfaces(optional) |
|||
|
CRI : Ra ≥70, Ra ≥95(Optional) |
DMX wireless receiver |
|||
|
DMX wireless transmitter(optional) |
||||
|
Cto |
||||
|
Linear CTO system(0-100%) |
Housing And Ingression Protection |
|||
|
High tensile cast aluminum + high temperature plastics, IP66 |
||||
|
Prism |
||||
|
1pc of 4-facet circular prism, bi-directional rotation |
Working Temperature |
|||
|
with varied speeds with indexing function |
Working temperature 45℃ at maximum |
|||
|
Note:If the ambient temperature is below minus 20℃, |
||||
|
Frost |
please reset a projector after preheating it by striking | |||
|
1frost filter ( 0-100% linear ) |
the lamp for more than 30 minutes. | |||
|
|
||||
|
Effect Wheel |
Weight | |||
|
1 animation effect wheel, bi-directional rotation with varied speeds |
Net weight 61Kg | |||
|
|
||||
|
Dimmer |
Accessories | |||
|
Linear electronic dimmer 0-100% with 16 bit control |
G clamp 2 Pcs | |||
|
3 dimmer speeds |
XLR connector 1 Set Male and female |
|||
|
4 dimmer gamma curves |
Safety cord 2 Pcs |
|||
|
Dimmer frequency(1.2K-25K) good for 4K high speed |
User manual 1 Pc |
|||
| video camera |
Ω clamp 2Pcs Optional |
|||
|
Power cord 1 Pc |
||||
|
Head Movement |
||||
|
Pan 540º, Tilt 270º with auto position correction |
Strobe | |||
|
and16 bit control |
Electronic strobe, 0.3~25 F.P.S |
|||
|
Control |
Iris | |||
|
International standard DMX512 signal with 5-pin DMX512 interfaces |
Linear iris 5-100% with macros |
|||
|
RDM protocol |
||||
|
ArtNet protocol(optional) |
Beam Angle | |||
|
35channels in short mode, 38channels in standard mode,54channel in extended mode |
Linear zoom 6°～ 56°with 16 bit precision | |||
|
Master/Salve synchronized control mode |
||||
|
Standalone mode |
||||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| Color Wheel | |||
|
6 exchangeable colors+ open |
|||
|
Half color effect, Stepping/linear colors |
|||
|
Bi-directional color rainbow effect with variable speeds |
|||
| Fixed Gobo | |||
| 1 Fixed Gobo Wheel: 7 exchangeable gobos+ open | |||
|
Shake effect with varied speeds and bi-directional rotation with varied speeds |
|||
| Rotating Gobo | |||
|
1 rotating gobo wheel: 6 exchangeable+ open, glass/metal gobos |
|||
|
Bi-directional rotation, indexing, shake with varied speeds |
|||
|
bi-directional scrolling with varied speeds |
|||
| Framing | |||
|
Framing module:4 framing blades to make graphics with different sizes and shapes |
|||
|
Each blade to make full curtain effect |
|||
|
Bi-directional continual rotation for the whole module |
|||
