Input Voltages | Fan Mode | ||
100V-240V AC，50/60Hz | Standard mode and theater modes. Theater mode is quiet mode | ||
Input Power | Fixture Types | ||
1550W@220V | Including moving head light, fixed-focus profile light, zoom profile light | ||
1700W@100V | Moving head light with beam angle range(6-54°) | ||
Power factor: PF>0.95 | Fixed focus profile light with beam angle options including 6°,10°,19°,26°,36°,50° | ||
Zoom profile light with beam angle ranges including 6-15°,15-35°,35-54° | |||
Light Sources | (Note: Auto quiet theater mode for fixed focus profile light and zoom profile light) | ||
1200W white LED module (6900K), CRI: Ra≥95, R9≥95 | |||
CRI Mode | |||
Running at high CRI mode via DMX channel to ensure high CRI optical effect | |||
Cto | |||
Linear CTO system(0-100%, 1800K-6500K) | Control | ||
International standard DMX512 signal and RDM function | |||
Effect Wheel | 47channels in short mode, 52channels in standard mode,67channel in extended mode | ||
1 animation effect wheel, bi-directional rotation with varied speeds | Art Net protocol , sCAN protocol(optional), DMX512 wireless control | ||
Iris | Control Interface | ||
Linear iris 5-100% with macros | DMX512 ports（5-pin） | ||
Ethernet port RJ45 | |||
| Prism | |||
1pc of 4-facet circular prism+1 pc of linear prism | Other Functions | ||
| bi-directional rotation with varied speeds with indexing function | Pan and Tilt speeds adjustable | ||
Pan and Tilt swappable and invertible | |||
Frost | High precision magnet sensor for positioning | ||
2 frost filters: 1 heavy frost filter + 1 light frost filter (0-100% linear ) | 3.2-inch touch color screen | ||
Chinese and English menus | |||
Beam Angle | Screen automatic lock –up while standby | ||
Linear zoom 6°～ 54°with 16 bit precision | Error diagnostic system with sensors | ||
Smart fan cooling system | |||
Focus | Display of fixture hours and software versions | ||
Linear focus with auto-focus function | Modular construction for easy maintenance | ||
Isolated input signals | |||
Dimmer | Firmware update via DMX cable or USB port | ||
Linear electronic dimmer 0-100% with 16 bit control | |||
3 dimmer speeds | IP Rating | ||
4 dimmer gamma curves | IP20 | ||
Dimmer frequency(1.2K-25K) | |||
Operation Temperature | |||
Strobe | 45℃ at Maximum | ||
Electronic strobe, 0.3~25 F.P.S | |||
Weight | |||
Head Movement | Net weight 45Kg | ||
Pan 540o, Tilt 270o with auto position correction and 16 bit control | |||
Accessories | |||
Advanced Macros | G clamp2 Pcs | ||
Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K | XLR connector 1 Set Male and female | ||
Standard color macros: 89 color options | Safety cord2 Pcs | ||
User manual1 Pc | |||
Brightness Calibration Function | Ω clamp2 Pcs Optional | ||
With brightness calibration function to calibrate initial brightness | |||
for a single fixture or multiple ones and store brightness | |||
| values into the fixtures | |||
| CMY | |||
CMY linear coloring mixing system with macros | |||
| Color Wheel | |||
2 Color Wheels | |||
Color wheel1: Red,Yellow,Blue,Green,Pink,Orange,Open | |||
Color Wheel2: Dark Red,Dark Magenta,Light Yellow,Light Green,Dark Cyan, UV, Open | |||
| Bi-directional rainbow effect with variable speeds | |||
Full color/half color/linear color | |||
| Fixed Gobo | |||
1 rotating gobo wheel: 6 exchangeable+ open | |||
Bi-directional rotation, indexing, shake with varied speeds | |||
bi-directional scrolling with varied speeds | |||
| Rotating Gobo | |||
1 Fixed gobo wheel: 7 exchangeable gobos+ open | |||
Shake effect with varied speeds and bi-directional rotation with varied speeds | |||
| Framing | |||
Framing module:4 framing blades to make graphics with different sizes and shapes | |||
| Each blade to make full curtain effect .Continual and bi-directional rotation for the whole module | |||
Framing module rotates bi-directionally up to 360 °and continually, each framing blade produces full curtain effect | |||
