Input Voltage | Control | ||
100V-240V AC，50/60Hz | International standard DMX512 signal , 5 pin interface(Optional 3pin interface) | ||
RDM control protocol | |||
Input Power | ArtNet protocol(Optional) | ||
950W@220V AC | 35channels in short mode, 38channels in standard mode,54channel in extended mode | ||
980W@100V AC | Master/slave synchronized mode | ||
Power factor: PF>0.95 | Stand-alone mode | ||
Light Source | Other Functions | ||
Lamp 600W ,LED white (8000K, 20000hrs) | Adjustable Pan & Tilt speeds | ||
| Ra≥70 | Pan and Tilt swappable and invertible | ||
Ra≥95 , R9≥90 (Optional) | Fixture and lamp hours’ display | ||
Color screen, Chinese-English menus, brightness and contrast adjustable | |||
Diagnostic system with sensors | |||
CTO | Software version display | ||
Linear CTO system(0-100%) | Protection and insulation of input signals | ||
Modular construction for easy maintenance | |||
Prism | ArtNet interface(Optional) | ||
1pc 4 facet prism, bi-directional rotation with varied speeds and indexing function | DMX512 wireless receiver | ||
DMX512 wireless transmitter (optional) | |||
Frost | |||
Linear frost (0-100%) | Housing | ||
High tensile cast Aluminum, high temperature resistant/anti-UV ABS, IP66 | |||
Effect Wheel | |||
1 exchangeable graphic effect wheel, bi-directional rotation with varied speeds | Ambient Temperature | ||
-20℃ ~ 45℃ | |||
Focus | Note: if the ambient temperature is below -20°C | ||
0-100% linearly adjustable by DMX | please preheat the lamp more than 30 minutes and reset it again. | ||
Dimmer | Weight | ||
Linear dimmer 0-100% | 56Kg | ||
3 dimmer speeds | |||
4 dimmer gamma curves | Packaging | ||
Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera | Standard: carton 855×655×815(mm) | ||
Optional: flight case 695x535x870(mm) | |||
Iris | |||
Linear iris 5-100% with macros | Accessories | ||
G clamp 2 Pcs | |||
Strobe | XLR connector 1 Set Male and female | ||
Double shutter blades, 0.3~25 F.P.S | Safety cord 2 Pc | ||
This manual 1 Pc | |||
Head Movement | Ω clamp 2 Pcs Optional | ||
Pan 540o, Tilt 270o with auto position correction | Power Cord 1 Pc | ||
Beam Angle | |||
Beam angle: 6°～ 56° Linear zoom with 16 bit precision | |||
| CMY | |||
CMY linear coloring mixing system with macros | |||
| Color Wheel | |||
1 Color Wheel：6 color + white | |||
Bi-directional rainbow effect with variable speeds and half color effect | |||
Linear /stepping color changing | |||
| Rotating Gobo | |||
1 rotating gobo wheel: 6 exchangeable+ white, glass or metal gobos | |||
Bi-directional rotation, indexing, shake with varied speeds, bi-directional | |||
| scrolling with varied speeds | |||
| Fixed Gobo | |||
1 fixed gobo wheel | |||
7 exchangeable gobos+ white | |||
Shake effect with varied speeds and bi-directional rotation with varied speeds | |||
| Framing | |||
Continual rotation with graphics with different sizes and shapes | |||
4 blades for complete curtain effect | |||
