Input Voltage |
Control |
||
|
100V-240V AC，50/60Hz |
International standard DMX512 signal , 5 pin interface |
||
|
RDM control protocol |
|||
|
Input Power |
ArtNet protocol |
||
|
1140W @ 100V AC |
27channels in short mode, 31channels in standard mode,38channel in extended mode |
||
|
1080W @ 220V AC |
Master/Slave mode |
||
|
Power factor: PF>0.9 |
Stand-alone mode |
||
|
Self test mode |
|||
|
Light Source |
|||
|
LED 800W (8000K,20000hrs) |
Other Functions |
||
| Ra ≥70 |
Adjustable Pan & Tilt speeds |
||
|
Ra ≥90, R9≥90 (Optional) |
Pan and Tilt swappable and invertible |
||
|
|
Fixture and lamp hours’ display |
||
|
Color screen, Chinese-English menus, brightness and contrast adjustable |
|||
|
Cto |
Diagnostic system with sensors |
||
|
Linear CTO system(0-100%) |
Software version display |
||
|
Protection and insulation of input signals |
|||
|
Prism |
Modular construction for easy maintenance |
||
|
1pc 4 facet prism, bi-directional rotation with varied speeds and indexing function |
ArtNet interface |
||
|
DMX512 wireless receiver |
|||
|
Frost |
DMX512 wireless transmitter (optional) |
||
|
Linear frost (0-100%) |
|||
|
Housing |
|||
|
Effect Wheel |
High tensile cast aluminum and high temperature resistant ABS, IP66 |
||
|
1 exchangeable graphic effect wheel, bi-directional rotation with varied speeds |
|||
|
Ambient Temperature |
|||
|
Focus |
-20℃ ~ 45℃ |
||
|
0-100% linearly adjustable by DMX |
Note: if the ambient temperature is below -20°C |
||
|
please preheat the lamp more than 30 minutes and reset it again |
|||
|
Dimmer |
|||
|
Linear dimmer 0-100% |
Weight | ||
|
3 dimmer speeds |
55Kg |
||
|
4 dimmer gamma curves |
|||
|
Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera |
Accessories |
||
|
G clamp 2 Pcs |
|||
|
Iris |
XLR connector 1 Set Male and female |
||
|
Linear iris 5-100% with macros |
Safety cord 2 Pcs |
||
|
User manual 1 Pc |
|||
|
Strobe |
Ω clamp 2 Pcs Optional |
||
|
Double shutter blades, 0.3~25 F.P.S |
Power cord 1 Pc | ||
|
Head Movement |
|||
|
Pan 540º, Tilt 270º with auto position correction |
|||
|
Beam Angle |
|||
|
Linear zoom 6°～ 56°with 16 bit precision |
|||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| Color Wheel | |||
|
1 Color Wheel：6 color + white |
|||
|
Bi-directional rainbow effect with variable speeds and half color effect |
|||
|
Linear /stepping color changing |
|||
|
|
|||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 7 interchangeable gobos plus open |
|||
|
Bi-directionally rotatable, and shakable effect at variable speeds |
|||
| Rotating Gobo | |||
|
2 rotating gobo wheels: 6 exchangeable+ white, glass or metal gobos |
|||
|
Bi-directional rotation, indexing, shake with varied speeds, bi-directional |
|||
|
scrolling with varied speeds |
|||
