Input Voltages | Focus | ||
100V~240V AC，50/60Hz | DMX linear Focus | ||
Rated Power | Zoom | ||
650W @ 220V | DMX linear Zoom | ||
Light Source | Dimmer/Strobe | ||
Lamp SIRIUS HRI? 420W S (7700K) | 0-100% Linearly adjustable/ Double shutter blades, 0.3~25 F.P.S | ||
Manufacturers Rated Lamp Life | Head Movement | ||
2,500 hrs typical @ 420W (SO) | Pan 540o, Tilt 270o with auto position correction | ||
4,000 hrs typical @ 330W (Eco) | |||
Beam Angle | |||
Colors | Beam Mode: 2.3°-- 10°Linear Adjustment | ||
1 Color wheel: 13colors(plus 1CTO)+ Open, | Spot Mode: 5°-- 40°Linear Adjustment | ||
rainbow effect with bi-directional and variable speeds, | Wash Mode: 5°-- 50°Linear Adjustment | ||
Stepping/linear color changing | |||
CMY linear color mixing with macros | Control | ||
DMX512, 5 pin interfaces | |||
24channels in short mode, 28channels in standard mode , 33channels in extended mode | |||
Fixed Gobo Wheel | Self-test mode | ||
1 Fixed gobo wheel: | |||
10 gobos +open+ animation effect | Other Functions | ||
| Bi-directionally rotatable, | Adjustable Pan & Tilt speeds | ||
and shakable at variable speeds, | Lamp’s and fixture’s hours displayed | ||
2channels to shift between gobos and animation effects. | Modular Structure for easy maintenance | ||
| DMX512 wirless reciever | ||
Rotating Gobo Wheel | Optional DMX512 Wireless Transmitter | ||
| 1 Rotating gobo wheel: | |||
9Interchangeable Gobos +Open | Housing | ||
Bi-directionally rotatable, | High temperature ABS, IP20 | ||
and shakable at variable speeds | |||
| Gobo Replaceable | Net Weight | ||
22.2Kg | |||
Prism | |||
2Pcs,(STD 8-facet and 16 facet Prisms) | Operation Temperature | ||
Bi-directional rotation with variable speeds | Maximum ambient temperature: 40°C | ||
(options: 3-facet/ 16-facet liner prism or gradient prism) | |||
Accessories | |||
Independent Diffuser | G clamps2 Pcs | ||
| 1Pcs of independent diffuser | XLR connector1 Set Male and female | ||
Safety cord 1 Pc | |||
| Frost | User manual 1 Pc | ||
| 1Pc frost filter | Ω clamps 2 Pcs Optional | ||
