| Input Voltage |
Head Movement |
||
| 100V-240V AC，50/60Hz |
Pan 540º, Tilt 270º with auto position correction |
||
| Input Power |
Beam Angle |
||
|
1050W@220V AC |
Linear zoom 6°～ 56°with 16 bit precision |
||
|
1100W@100V AC |
|||
|
Control |
|||
|
Light Source |
International standard DMX512 signal , 5 pin interface(Optional 3pin interface) |
||
|
LED 800W (8000K, 20000hrs) |
RDM control protocol |
||
|
Ra≥70 |
ArtNet protocol |
||
|
Ra≥95,R9≥90 LED（Optional） |
27channels in short mode, |
||
|
31channels in standard mode,38channel in extended mode |
|||
|
Colors |
Master and slave synchronized control mode |
||
|
CMY linear coloring mixing system with macros |
Stand-alone mode |
||
|
1 Color Wheel |
Master mode |
||
|
6 colors+ white |
|||
|
Bi-directional rainbow effect with variable speeds and half color effect |
Other Functions |
||
|
Linear /stepping color changing |
Adjustable Pan & Tilt speeds |
||
|
Pan and Tilt swappable and invertible |
|||
| CTO |
Fixture and lamp hours’ display |
||
| Linear CTO system(0-100%) |
Color screen, Chinese-English menus, brightness and contrast adjustable |
||
|
Diagnostic system with sensors |
|||
|
Gobos |
Built-in rechargeable battery for settings via control panel without mains power |
||
|
2 rotating gobo wheels: 6 exchangeable+ white, glass or metal gobos |
Software version display |
||
|
Bi-directional rotation, indexing, shake with varied speeds, bi-directional |
Protection and insulation of input signals |
||
|
scrolling with varied speeds |
Modular construction for easy maintenance |
||
|
ArtNet interface |
|||
|
Prism |
DMX512 wireless receiver |
||
|
1pc 4 facet prism |
DMX512 wireless transmitter(Optional） |
||
|
bi-directional rotation with varied speeds and indexing function |
|||
|
Housing |
|||
|
Frost |
High temperature resistant, IP20 |
||
|
Linear frost (0-100%) |
|||
|
Net Weight |
|||
|
Effect Wheel |
42.5Kg |
||
|
1 graphic effect wheel, bi-directional rotation with varied speeds |
|||
|
Ambient Temperature |
|||
|
Focus |
-20°C～45°C |
||
|
0-100% linearly adjustable by DMX |
|||
|
Accessories |
|||
|
Dimmer |
G clamp 2 Pcs |
||
|
Linear dimmer 0-100% |
XLR connector 1 Set Male and female |
||
|
3 dimmer speeds |
Safety cord 2 Pc |
||
|
4 dimmer gamma curves |
User manual 1 Pc |
||
|
Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera |
Ω clamp 2 Pcs Optional |
||
|
Iris |
|||
|
Linear iris 5-100% with macros |
|||
|
Strobe |
|||
|
Double shutter blades, 0.3~25 F.P.S |
|||
