Electric parameters Input voltage: 100V~240V AC,50/60Hz Power consumption: 670W @ 220V Rated current: 3.0A @ 220V Power factor: PF>0.9 Light sources Light sources: 500W laser module Color temperature: 9000K Rated life: 12000hrs Prism/frost: 2 prism wheels: 1 wheel (an 8-facet circular prism+ a 4-facet linear prism )+1 wheel (a 16-facet circular prism + a frost filter), prisms overlapped. Other prism options 17- available. Focus DMX linear focus Strobe/dimmer Double flag strobe,0.3-25 F.P.S. / linear dimmer Movements Pan (0°-540°),Tilt( 0°-270°) with auto positioning correction function Beam angle Beam angle:0.8° |
Control International standard DMX 512 signal,5-pin XLR connectors Short Mode21 channels,standard Mode 25channels,extended mode 28channels Self test mode Other functions Pan and Tilt speeds adjustable Lamp hours and fixture hours displayed Modular construction easy for maintenance Wireless receiver Wireless transmitter ( Optional) ArtNet and sACN ( Optional) Housing and ingress protection Cast aluminum and high temperature and UV resistant ABS with IP66 Weight Net weight:39.5 Kg Ambient temperature -20 °C ~ 45 °C Note:If a fixture runs with the ambient temperature below 0 Celsius, it should be heated for some time(less than 20 minutes based on actual conditions) before turning on the laser module. |
【Version:20240311】 |
