Electric parameters Input voltage: 100V~240V AC，50/60Hz
Light sources 300 W RGB laser engine Color temperature 7500K Rated life ≥20000hrs Lumens ≥10000lm Nominalwavelengthofredlaser 638nm Nominalwavelengthofgreenaser 520nm Nominalwavelengthofbluelaser 450nm Initial beam’s diameter 80~120mm
Prism： 2 set prism
Frost 1 pc of frost filter
Focus DMX linear focus
Strobe/dimmer Double flag strobe，0.3-25 Hz/ linear dimmer |
Movements Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function
Beam angle Beam angle：0.6°
Control International standard DMX 512 signal,3pin XLR connectors(optional 5-pin)
Other functions Pan and Tilt speeds adjustable DMX, Art-Net and sACN protocols
Housing and ingress protection Cast aluminum and high temperature and UV resistant ABS with IP65
Weight Net weight：21Kg
Ambient temperature 45 °C at maximum Note: while ambient temperature below zero, please preheat a fixture for some time(normally less than 20 minutes) based on actual temperature before turning on the laser engine.
|
|
|
|
|
|
【Version：20250226】 |
